Desktop SMT Placement Machine
● Kev kub ceev ntawm 2500-3000CPH
● Tus nqi qis
●Novice-tus phooj ywg thiab siv tau yooj yim
● Tau tshaj 0402 thiab tshwj xeeb - zoo li cov khoom
Hauj lwm lawm
Kev tsis
Lub Desktop SMT Placement Machine, lub npe hu ua Desktop Surface Mount Technology (SMT) Component Placement System thiab feem ntau hu ua "desktop placement machine" lossis "small - scale P&P equipment" hauv kev lag luam, yog cov cuab yeej tseem ceeb hauv SMT ntau lawm kab. Nws lub luag haujlwm tseem ceeb yog siv cov qauv siv tshuab ua haujlwm kom raug thiab ua tau zoo rau qhov chaw nto - Mount Devices (SMDs) xws li capacitors, resistors thiab integrated circuits mus rau Printed Circuit Boards (PCBs), nteg lub hauv paus rau tom ntej soldering. Piv nrog rau loj - scale industrial placement machines, nws muaj qhov zoo ntawm "miniaturization, yooj thiab yooj yim ntawm kev ua haujlwm", tsis txwv los ntawm qhov chaw (tuaj yeem xa mus rau hauv kev lag luam R & D lub chaw soj nstuam, kev cob qhia me me thiab tus kheej hauv tsev studios), thiab yog qhov tsim nyog rau me me - batch ntau lawm, qauv kev loj hlob thiab kev qhia kev cob qhia kev daws teeb meem. xav tau" hauv kev tsim hluav taws xob.
●Compact thiab yoog raws, tsis muaj qhov txwv qhov chaw:Boasts lub cev compact (tsuas yog 0.5-1㎡), yuav tsum tsis muaj kev cob qhia tshwj xeeb lossis cov kab ntau lawm. Nws tuaj yeem hloov tau yooj yim tso rau hauv tsev, chaw ua haujlwm, thiab chaw soj nstuam, thiab txav tau yooj yim.
● Yooj yim khiav lag luam, Tsawg nkag Barrier:Nruab nrog ib tug neeg intuitive - tshuab kev sib txuas lus thiab cov qauv kev tso kawm qauv. Tsis xav tau cov kws tshaj lij SMT engineers; Tom qab kev cob qhia yooj yim, cov neeg siv tuaj yeem ua tiav cov cuab yeej debugging thiab ua haujlwm, txo cov nqi zog.
●High Precision + High Speed, Sib npaug zoo thiab ua haujlwm:Features ib tug dual qhov chaw tso lub taub hau tsim, nrog ib tug qhov chaw tso kawm ntawm ± 0.02mm (tshaj nrog Cheebtsam los ntawm 0402 mus rau IC chips) thiab qhov siab tshaj plaws kev tso kawm ceev ntawm 6000 ntsiab lus ib teev. Rau me me -batch ntau lawm, nws efficiency yog 10-20 lub sij hawm siab dua li phau ntawv tso.
● Strong Compatibility, Dav Adaptability:Txhawb PCB qhov ntau thiab tsawg xws li 50mm × 50mm txog 300mm × 300mm thiab ntau hom SMD Cheebtsam. Nws kuj tseem tuaj yeem nthuav dav los txhawb los ntawm - qhov chaw muab tso rau hauv, hloov mus rau ntau qhov xwm txheej.
Cov ntaub ntawv Parameter
| tem | Paub meej |
|---|---|
| Khoom qauv | V5 Pro Basic Version |
| Core Parameters | Tsis Muaj Txoj Haujlwm Tso Cai |
| Configured Workbench | Tsis muaj |
| Kev Pom Kev Pom Kev | Simultaneous Shooting Placement, Sab saum toj 720P Standard Txhais Lub Koob Yees Duab |
| Txoj kev taw qhia | Lub koob yees duab hauv qab ntawm sab xis, Txoj Kev Ntev Ntev, cuam tshuam nrawm |
| Software System | PC & Mobile Chaw Taws Teeb Dual Control |
| Tus nqi - ntxiv Kev Pabcuam | 1 - xyoo Standard Warranty |
Desktop SMT Placement Machine daim ntawv thov
R & D thiab Sample Production: Thaum lub sij hawm tsim khoom tshiab, cov engineers hluav taws xob yuav tsum tau tshawb xyuas qhov ua tau ntawm PCB tsim. Lub tshuab muab tso rau hauv lub desktop tuaj yeem paub qhov kev tso kawm sai ntawm cov khoom me me (1 - 100 daim), ua kom luv R & D iteration voj voog. Nws yog qhov tshwj xeeb tshaj yog tsim rau cov qauv tsim ntawm cov neeg siv khoom siv hluav taws xob thiab kev tswj hwm kev lag luam.
Small - Batch Production: Rau me me - cov lag luam hluav taws xob loj thiab cov koom haum ua lag luam uas cuam tshuam nrog kev txiav txim siab (xws li cov sensors tshwj xeeb thiab cov khoom siv rau cov khoom siv kho mob me me), tsis tas yuav nqis peev rau hauv kev lag luam - qib ntau lawm kab. Lawv tuaj yeem ua tiav cov khoom lag luam ruaj khov los ntawm lub tshuab tso rau hauv desktop, tswj cov nqi tsim khoom.
Kev qhia thiab kev cob qhia: Cov tsev kawm qib siab ua haujlwm nrog cov ntaub ntawv xov xwm hluav taws xob loj thiab SMT cov tsev kawm txuj ci thev naus laus zis tuaj yeem ua tiav kev qhia ua haujlwm siv lub tshuab tso rau lub desktop. Qhov no tso cai rau cov tub ntxhais kawm kom paub txog kev txawj ntse xws li kev tso kawm, cov cuab yeej debugging, thiab parameter optimization, uas yog nyob rau hauv txoj kab nrog kev siv cov scenarios.
Adaptability rau cov khoom siv hauv ntau qhov chaw: Cov PCBs tom qab kev tso kawm tau dav siv hauv kev lag luam xws li khoos phis tawj, khoom siv hluav taws xob, khoom siv tswj kev lag luam, khoom siv hluav taws xob kho mob, khoom siv hluav taws xob tsheb, tub rog electronics, thiab cov khoom siv sib txuas lus (cov khoom me me ntawm cov chaw nres tsheb hauv paus). Nyob rau tib lub sijhawm, nws tau sib xws nrog los ntawm - qhov chaw muab tso rau thiab txhawb nqa lub flip - nti ntim txheej txheem.
txoj cai ua haujlwm
Visual Positioning Calibration:
Ua-hauv cov koob yees duab kev lag luam thiab cov duab lees paub algorithms ntes PCB cov ntsiab lus siv thiab SMD txoj hauj lwm sib txawv, suav cov kev sib koom ua ke kom haum rau qhov tseeb.
Nqus Suction Xaiv-thiab-Qhov chaw:
Ob chav tso taub hau nrog lub tshuab nqus tsev hloov pauv tau nqus SMDs ntawm qhov tsis zoo siab, hloov lawv, thiab tso lub tshuab nqus tsev los tso cov khoom ntawm PCB pads.
Tsis Siv Neeg Pub Adaptation:
Feeder slots kho SMD daim kab xev, thiab lub kaw lus tsav cov tshuab pub rau thawb cov khoom mus rau qhov chaw xaiv tau nyob rau hauv ib ntus, sib piv cov khoom sib txawv.
Servo- Tsav Tsheb Tsav Tsheb:
X/Y/Z-axis servo motors, coj los ntawm qhov chaw cov ntaub ntawv, tswj kev tso chaw taub hau 'micro- theem txav (kab rov tav hloov mus, qhov siab hloov kho) kom ruaj khov, raug tso.
FAQ
1.Dab tsi tivthaiv / PCB qhov ntau thiab tsawg tuaj yeem ua tau?
Feem ntau SMDs los ntawm 0402 mus rau TQFP144, PCBs 50mm × 50mm-300mm × 300mm; kos rau 0201/01005 lossis loj dua PCB txhawb yog tias xav tau.
2.Yuav ua li cas sib npaug qhov tseeb thiab ceev rau cov khoom me me?
Lub hom phiaj rau ± 0.02mm-± 0.05mm qhov tseeb (ua ntej qhov no) thiab 3,500-8,000 CPH; zam kev lag luam precision rau kev ceev (kev cuam tshuam rau soldering tawm los).
3.Cov nqi zais dab tsi muaj nyob dhau ntawm kev yuav khoom?
Consumables (nozzles), servo lub cev muaj zog tu, feeder adapters, thiab qis - qauv nqi yuav muaj ntau dua - nqi hloov lub sij hawm.
4.Nws puas tuaj yeem ua qhov txawv - daim ntawv / los ntawm - qhov khoom?
Cov qauv yooj yim rau cov qauv SMDs; cov kev xaiv hloov kho tau txhawb nqa los ntawm - qhov chaw, thaum vibration feeders kov yooj yim khib- cov ntaub ntawv (xws li, LEDs).
5.Kuv puas xav tau cov kws tshaj lij engineers ua haujlwm?
Tsis muaj -intuitive interfaces + templates cia cov neeg siv ua haujlwm tom qab kev cob qhia yooj yim; yooj yim txij nkawm (nozzle tu) yog ncaj nraim.
6.Dab tsi software nta tseem ceeb rau me me -batch workflows?
Gerber/CAD/BOM ntshuam, luag-thiab-poob programming, yield stats, thiab ceev program hloov mus txiav sijhawm hloov pauv.
